AMD Ryzen 7 8700G Processor with Radeon 780M Graphics – Overview
Cores / threads
8 cores, 16 threads
Zen 4 architecture, formerly codenamed Phoenix
8 cores, 16 threads
Zen 4 architecture, formerly codenamed Phoenix
Clock speed
Up to 5.1GHz boost
4.2GHz base clock, unlocked for overclocking
Up to 5.1GHz boost
4.2GHz base clock, unlocked for overclocking
Graphics
AMD Radeon 780M
12 graphics cores at 2900 MHz, up to 4 displays
AMD Radeon 780M
12 graphics cores at 2900 MHz, up to 4 displays
AI engine
Ryzen AI, up to 16 TOPS
On-chip NPU for supported AI features
Ryzen AI, up to 16 TOPS
On-chip NPU for supported AI features
Cache
24MB L2 + L3
8MB L2 and 16MB L3 cache
24MB L2 + L3
8MB L2 and 16MB L3 cache
TDP
65W
Configurable 45-65W; maximum operating temperature 95 °C
65W
Configurable 45-65W; maximum operating temperature 95 °C
Memory
DDR5, dual channel
DDR5-5200 with two DIMMs, up to 256GB
DDR5, dual channel
DDR5-5200 with two DIMMs, up to 256GB
Connectivity
PCIe 4.0, 2 x USB4
20 native PCIe lanes (16 usable), USB4 at 40Gbps
PCIe 4.0, 2 x USB4
20 native PCIe lanes (16 usable), USB4 at 40Gbps
Warranty
3 Year Carry-In
AMD manufacturer warranty, boxed processor
3 Year Carry-In
AMD manufacturer warranty, boxed processor
AMD Ryzen 7 8700G Processor with Radeon 780M Graphics Specifications
| General | |
|---|---|
| Brand | AMD |
| Model | Ryzen 7 8700G |
| Part number | 100-100001236SBX |
| Tray part number | 100-000001236 |
| EAN | 730143317696 |
| Former codename | Phoenix |
| Launch date | Q1 2024 |
| Processor | |
| Architecture | Zen 4 |
| Cores | 8 |
| Threads | 16 |
| Base clock | 4.2GHz |
| Max boost clock | Up to 5.1GHz |
| L2 cache | 8MB |
| L3 cache | 16MB |
| Process | TSMC 4nm FinFET |
| Unlocked for overclocking | Yes (Precision Boost Overdrive, Curve Optimizer, EXPO) |
| Default TDP | 65W (configurable 45-65W) |
| Max operating temperature | 95 °C |
| AI engine | Ryzen AI NPU, up to 16 TOPS |
| Platform | |
| Socket | AM5 |
| Supported chipsets | A620, B650, B650E, X670, X670E, B840, B850, X870, X870E |
| PCI Express | PCIe 4.0, 20 native lanes (16 usable) |
| Native USB | 2 x USB4 (40Gbps), 2 x USB 3.2 Gen 2 (10Gbps), 1 x USB 2.0 |
| Memory | |
| Memory type | DDR5 UDIMM (ECC with platform support) |
| Memory channels | 2 |
| Max memory | 256GB |
| Memory speed | DDR5-5200 (2 DIMMs), DDR5-3600 (4 DIMMs) |
| Graphics | |
| Integrated graphics | AMD Radeon 780M, 12 cores, 2900 MHz |
| Display outputs supported | DisplayPort 2.1, HDMI 2.1, up to 4 displays |
| Features | DirectX 12, AMD FreeSync, HDCP 2.3 |
| In the Box and Warranty | |
| In the box | AMD Ryzen 7 8700G processor |
| Warranty | 3 Year AMD Carry-In |
About the AMD Ryzen 7 8700G Processor with Radeon 780M Graphics
The AMD Ryzen 7 8700G is an eight-core, sixteen-thread AM5 processor that combines Zen 4 CPU cores with Radeon 780M graphics, one of the strongest integrated GPUs on a desktop chip. It suits compact gaming PCs, home theatre builds and work machines that need decent graphics without a separate card. Boost reaches 5.1GHz, and a Ryzen AI engine rated at up to 16 TOPS handles supported AI tasks. It supports DDR5 and USB4. This SBX boxed version is listed by the supplier as processor only, so plan for a cooler.
