AMD Ryzen 7 PRO 9745 Processor (MPK) – Overview
Cores / threads
8 cores, 16 threads
Zen 5 architecture with simultaneous multithreading
8 cores, 16 threads
Zen 5 architecture with simultaneous multithreading
Clock speed
Up to 5.4GHz boost
3.8GHz base clock, locked multiplier
Up to 5.4GHz boost
3.8GHz base clock, locked multiplier
Cache
40MB L2 + L3
8MB L2 and 32MB L3 cache
40MB L2 + L3
8MB L2 and 32MB L3 cache
TDP
65W
Default TDP; maximum operating temperature 95 °C
65W
Default TDP; maximum operating temperature 95 °C
Socket
AM5
For A620, B650, X670, B840, B850 and X870 series boards
AM5
For A620, B650, X670, B840, B850 and X870 series boards
Memory
DDR5, dual channel
DDR5-5600 with two DIMMs, up to 192GB, ECC capable
DDR5, dual channel
DDR5-5600 with two DIMMs, up to 192GB, ECC capable
Graphics
AMD Radeon Graphics
2-core integrated GPU at 2200 MHz
AMD Radeon Graphics
2-core integrated GPU at 2200 MHz
Business features
AMD PRO technologies
DASH manageability, Memory Guard and Secure Processor
AMD PRO technologies
DASH manageability, Memory Guard and Secure Processor
Warranty
3 Year Carry-In
AMD processor warranty, supplied as MPK
3 Year Carry-In
AMD processor warranty, supplied as MPK
AMD Ryzen 7 PRO 9745 Processor (MPK) Specifications
| General | |
|---|---|
| Brand | AMD |
| Model | Ryzen 7 PRO 9745 |
| Part number (MPK) | 100-100001408MPK |
| Tray part number | 100-000001408 |
| Launch date | 16/09/2025 |
| Processor | |
| Architecture | Zen 5 |
| Cores | 8 |
| Threads | 16 |
| Base clock | 3.8GHz |
| Max boost clock | Up to 5.4GHz |
| L1 cache | 640KB |
| L2 cache | 8MB |
| L3 cache | 32MB |
| Process | TSMC 4nm FinFET (CPU cores), TSMC 6nm FinFET (I/O die) |
| Unlocked for overclocking | No |
| Default TDP | 65W |
| Max operating temperature | 95 °C |
| Platform | |
| Socket | AM5 |
| Supported chipsets | A620, B650, B650E, X670, X670E, B840, B850, X870, X870E |
| PCI Express | PCIe 5.0, 28 native lanes (24 usable) |
| Native USB | 4 x USB 3.2 Gen 2 (10Gbps), 1 x USB 2.0 |
| Memory | |
| Memory type | DDR5 UDIMM (ECC with a supporting motherboard) |
| Memory channels | 2 |
| Max memory | 192GB |
| Memory speed | DDR5-5600 (2 DIMMs), DDR5-3600 (4 DIMMs) |
| Graphics and Business Features | |
| Integrated graphics | AMD Radeon Graphics, 2 cores, 2200 MHz |
| AMD PRO technologies | Yes, with DASH manageability |
| In the Box and Warranty | |
| In the box | AMD Ryzen 7 PRO 9745 processor AMD Wraith Stealth CPU cooler |
| Warranty | 3 Year AMD Carry-In |
About the AMD Ryzen 7 PRO 9745 Processor (MPK)
The AMD Ryzen 7 PRO 9745 brings eight Zen 5 cores and sixteen threads to AM5 business desktops, with boost clocks up to 5.4GHz and 32MB of L3 cache in a 65W TDP. It suits office workstations that run heavier spreadsheets, development tools or light content work and need to be managed remotely. AMD PRO features include DASH manageability, Memory Guard and the AMD Secure Processor, and ECC memory works on supported boards. Integrated Radeon graphics handle display output. It has a locked multiplier and comes as an MPK pack.
