Intel Core i3-14100 Processor (Tray) – Overview
Cores / threads
4 cores, 8 threads
4 Performance-cores with Hyper-Threading, no E-cores
4 cores, 8 threads
4 Performance-cores with Hyper-Threading, no E-cores
Clock speed
Up to 4.7GHz turbo
3.5GHz P-core base frequency
Up to 4.7GHz turbo
3.5GHz P-core base frequency
Cache
12MB Smart Cache
Plus 5MB total L2 cache
12MB Smart Cache
Plus 5MB total L2 cache
Power
60W base power
110W maximum turbo power
60W base power
110W maximum turbo power
Graphics
Intel UHD Graphics 730
24 execution units, up to 1.5GHz
Intel UHD Graphics 730
24 execution units, up to 1.5GHz
Memory
DDR5-4800 or DDR4-3200
Dual channel, up to 192GB
DDR5-4800 or DDR4-3200
Dual channel, up to 192GB
Socket
LGA1700
For Intel 600 and 700 series motherboards (BIOS dependent)
LGA1700
For Intel 600 and 700 series motherboards (BIOS dependent)
Expansion
20 PCIe lanes
PCIe 5.0 and 4.0, up to 1×16+4 or 2×8+4
20 PCIe lanes
PCIe 5.0 and 4.0, up to 1×16+4 or 2×8+4
Warranty
3 Year Carry-In
Supplied as tray, no cooler included
3 Year Carry-In
Supplied as tray, no cooler included
Intel Core i3-14100 Processor (Tray) Specifications
| General | |
|---|---|
| Brand | Intel |
| Model | Core i3-14100 |
| Part number (tray) | CM8071505092206 |
| S-spec / stepping | SRMX1 / H0 |
| Boxed ordering code | BX8071514100 |
| Code name | Raptor Lake |
| Launch date | Q1 2024 |
| Processor | |
| Total cores | 4 (4 Performance-cores, 0 Efficient-cores) |
| Threads | 8 |
| P-core base frequency | 3.5GHz |
| Max turbo frequency | 4.7GHz |
| Cache | 12MB Intel Smart Cache |
| Total L2 cache | 5MB |
| Processor base power | 60W |
| Maximum turbo power | 110W |
| Lithography | Intel 7 |
| Tjunction | 100 °C |
| Memory and Expansion | |
| Memory types | Up to DDR5-4800, up to DDR4-3200 |
| Memory channels | 2 |
| Max memory | 192GB |
| Max memory bandwidth | 76.8 GB/s |
| PCI Express | PCIe 5.0 and 4.0, 20 lanes max |
| PCIe configurations | Up to 1×16+4, 2×8+4 |
| Graphics and Package | |
| Integrated graphics | Intel UHD Graphics 730, 24 EUs, 1.5GHz max |
| Socket | FCLGA1700 |
| Thermal solution specification | PCG 2020C |
| In the Box and Warranty | |
| In the box | Intel Core i3-14100 processor (tray) No CPU cooler included |
| Warranty | 3 Year Carry-In |
About the Intel Core i3-14100 Processor (Tray)
The Intel Core i3-14100 is a four-core, eight-thread 14th Gen desktop processor for LGA1700 motherboards. All four cores are Performance-cores with Hyper-Threading, turbo up to 4.7GHz, and share 12MB of cache within a 60W base power rating. Built-in Intel UHD Graphics 730 drives displays without a graphics card, which makes it a practical choice for office PCs, home desktops and budget gaming builds that add a GPU later. It works with DDR5 or DDR4 depending on the board. This tray version contains only the processor, with no cooler.
